Documented for MVME162-014A.
Product Profile
MVME162-014A
- 25 MHz
- 4MB DRAM with programmable parity
- Ethernet; no VMEbus
- MVME162
Model-Specific VME Configuration
An A-revision designation of the 25 MHz MVME162-014 configuration with 4MB DRAM and Ethernet, supplied without the VMEbus interface.
The data on this page follows the exact Motorola order designation and does not add family options that are absent from this configuration.
Technical Data
MVME162-014A Specifications
| Product family | MVME162 |
|---|---|
| Processor | MC68LC040 with MMU |
| Processor clock | 25 MHz |
| DRAM | 4MB DRAM with programmable parity |
| Local SRAM / NVRAM | 512KB battery-backed SRAM |
| Integrated I/O configuration | Ethernet; no VMEbus |
| Ethernet interface | Present |
| SCSI interface | Not fitted |
| VMEbus interface | Not fitted |
| Revision notation | Motorola states that the A suffix denotes a major revision level |
| Form factor | 6U VMEbus embedded controller |
| Flash memory | 1MB |
| Nonvolatile memory | 8K × 8 NVRAM and time-of-day clock with battery backup |
| Expansion | Four IndustryPack interfaces |
| Operating temperature | 0 to 70 °C exit air with forced-air cooling |
| Storage temperature | -40 to 85 °C |
| Relative humidity | 5 to 90%, non-condensing |
| Power, +5 V | 3.5 A typical; 4.5 A maximum |
| Power, +12 V | 100 mA maximum |
| Power, -12 V | 100 mA maximum |
| Board dimensions | 233 × 160 × 17 mm |
| With connectors/front panel | 262 × 188 × 20 mm |
| Timers | Four 32-bit timers and watchdog timer |
Operating Characteristics
Operating Characteristics for MVME162-014A
DRAM
Documented for MVME162-014A.
Processor
Documented for MVME162-014A.
I/O
Documented for MVME162-014A.
Typical Applications
Typical Applications for MVME162-014A
System-Level Use
MVME162-014A is intended for VMEbus embedded-control installations requiring the exact processor, memory and interface combination shown in Motorola documentation.
Configuration Control
Match the complete MVME162-014A designation before installation because processor, memory, SCSI, Ethernet and VMEbus options vary by order code.
Frequently Asked Questions
MVME162-014A FAQ
What processor is fitted to MVME162-014A?
MVME162-014A uses the documented MC68LC040 with MMU processor configuration at 25 MHz.
How much DRAM does MVME162-014A provide?
MVME162-014A provides 4MB DRAM with programmable parity.
Which integrated interfaces are documented for MVME162-014A?
MVME162-014A is documented with Ethernet; no VMEbus.
What expansion architecture does MVME162-014A use?
MVME162-014A is a MVME162 embedded controller with the VMEbus and IndustryPack expansion resources stated in the official Motorola documentation.
What should be verified before installing MVME162-014A?
MVME162-014A should be checked against the chassis power, airflow, jumper, serial-interface and transition-module requirements documented for this exact configuration.
