Copy| Product Name | Motorola MVME147-022 / MVME147-022A VMEbus Processor Module |
| Item NO. | 2898103 |
| Weight | 0.1 kg = 0.2205 lb = 3.5274 oz |
| Category | MOTOROLA |
| Brand | MOTOROLA |
| Creation Time | 2026-08-20 |
Motorola VME Embedded Controller
Base and A-revision MVME147 order designations with 8MB parity DRAM; Motorola documents list 32 MHz for the base model and 33.33 MHz for the A revision.
Product Overview
Base and A-revision MVME147 order designations with 8MB parity DRAM; Motorola documents list 32 MHz for the base model and 33.33 MHz for the A revision.
The specification below follows the exact Motorola order designation and excludes family options that are not documented for this configuration.
Product Specifications
| Product family | MVME147 |
|---|---|
| Processor | MC68030 with MC68882 FPU |
| Processor clock | 32 MHz base / 33.33 MHz A revision |
| DRAM | 8MB DRAM with parity |
| Local SRAM / NVRAM | 4K × 8 battery-backed CMOS RAM |
| Integrated I/O configuration | Ethernet and SCSI |
| MVME147-022 | 32 MHz, 8MB parity DRAM, Ethernet |
| MVME147-022A | 33.33 MHz, 8MB, Ethernet and SCSI |
| Documented difference | Processor clock designation changes from 32 MHz to 33.33 MHz |
| Processor family | MC68030 with MC68882 floating-point coprocessor |
| Form factor | Double-high VMEbus module |
| Firmware | 147Bug debugger/diagnostics in EPROM |
| Local nonvolatile memory | 4K × 8 CMOS RAM with battery backup |
| Timers | Two 16-bit tick timers and watchdog timer |
| Serial interfaces | Four EIA-232-D serial ports |
| Parallel interface | 8-bit Centronics-compatible parallel port |
| Storage interface | SCSI interface with DMA |
| VMEbus functions | System controller, master, interrupter and requester |
| Operating temperature | 0 to 55 °C incoming air with forced-air cooling |
Key Features
The MVME147-022 / MVME147-022A configuration is defined by its processor clock, DRAM capacity, parity implementation and fitted SCSI/Ethernet interfaces. These order-code distinctions are preserved in the specification table.
MVME147-022: 32 MHz, 8MB parity DRAM, Ethernet. MVME147-022A: 33.33 MHz, 8MB, Ethernet and SCSI. Documented difference: Processor clock designation changes from 32 MHz to 33.33 MHz.
System Integration
MVME147-022 / MVME147-022A integrates processor, local memory, serial/parallel I/O and VMEbus resources. Ethernet and SCSI availability follows the exact model designation rather than the wider family capability.
Match the complete MVME147-022 / MVME147-022A designation before installation. Processor, memory, Ethernet, SCSI and VMEbus options vary by order code.
Frequently Asked Questions
MVME147-022 and MVME147-022A uses the documented MC68030 with MC68882 FPU processor configuration at 32 MHz base / 33.33 MHz A revision.
MVME147-022 and MVME147-022A provides 8MB DRAM with parity.
MVME147-022 and MVME147-022A is documented with Ethernet and SCSI.
MVME147-022 and MVME147-022A is a MVME147 embedded controller with the VMEbus and IndustryPack expansion resources stated in the official Motorola documentation.
MVME147-022 and MVME147-022A should be checked against the chassis power, airflow, jumper, serial-interface and transition-module requirements documented for this exact configuration.
