Fuel Gas
Pressure monitoring for fuel gases covered by DVGW Worksheet G 260.
LEGACY PRESSURE CONTROL
Honeywell FEMA
Honeywell FEMA
DWR06 Pressure Monitor
Mechanical maximum- and minimum-pressure supervision for approved industrial fuel, steam and hot-water applications, with a 0.1–0.6 bar setting range.
PRESSURE MONITORFEMA
0.1–0.6
BAR
BAR
MODELDWR06
0.1–0.6 barSETTING RANGE
10–50 mbarSWITCHING DIFFERENTIAL
6 barMAX. PERMISSIBLE PRESSURE
2 millionTESTED OPERATING CYCLES
Product Description
Mechanical Pressure Supervision
The Honeywell FEMA DWR06 is a mechanical pressure monitor for supervising maximum and minimum pressures. The DWR series is calibrated for rising pressure: the value selected on the scale corresponds to the switching point as pressure rises, while the reset point is lower by the switching differential.
Honeywell identifies DWR monitors for fuel gases covered by DVGW Worksheet G 260, liquid fuels such as fuel oil, steam systems and hot-water systems within the standards stated in the official product documentation. The rugged switching enclosure uses seawater-resistant die-cast aluminium.
DWR06 is the standard fixed-differential configuration. Adjustable differential belongs to the separate DWR06-203 configuration and must not be assumed for the base DWR06.
Official Technical Data
Honeywell FEMA DWR06 Specifications
Manufacturer / Product Line
Honeywell / FEMA
Model
DWR06
Product Type
Mechanical pressure monitor
Pressure Reference
Relative pressure
Adjustable Pressure Range
0.1 to 0.6 bar
Switching Differential
10 to 50 mbar (fixed for standard DWR06)
Maximum Permissible Pressure
6 bar
Bursting Pressure
≥100 bar, verified by TÜV test for DWR types
Calibration
Rising pressure
Switch / Rating
Single-pole changeover; 8 (5) A at 250 Vac
Pressure Connection
External G 1/2 A and internal G 1/4
Ambient Temperature
−20 to +70 °C for standard DWR
Maximum Medium Temperature
70 °C; higher medium temperatures require measures that keep the switching device within its limits
Mounting Position
Vertically upward or horizontal
Housing
Seawater-resistant die-cast aluminium
Enclosure Rating
IP54 for plug-connection housing 200
Product Lifecycle
Discontinued; no public discontinuation date or support end date stated by Honeywell
Applications & Features
Officially Identified Use Areas
Liquid Fuel
Monitoring in liquid-fuel applications, including fuel oil.
Steam & Hot Water
Pressure supervision within the steam and hot-water standards identified by Honeywell.
Maximum Pressure
Mechanical changeover contact for maximum-pressure monitoring circuits.
Minimum Pressure
Mechanical changeover contact for minimum-pressure monitoring circuits.
Long-Life Design
Special-construction pressure switch tested through 2 million operating cycles.
Installation Essentials
Verify Before Commissioning
- Disconnect electrical power before wiring or adjustment.
- Use a pressure gauge for precise switching-point adjustment; the scale provides an approximate value.
- Fasten only at the hexagon nearest the pressure connection—never use the housing or plug as a lever.
- For gas applications, the internal thread is permitted only up to 4 bar; use a flat sealing ring above 4 bar.
- Prevent condensation in the sensor and switching device below 0 °C.
- Installation and safety validation must be completed by qualified personnel under applicable local standards.
Lifecycle & Replacement
Discontinued Product — No Published Direct Successor
Official lifecycle statement: Honeywell marks the DWR Pressure Monitor series as discontinued. Honeywell's public product page does not state the discontinuation date, last-time-buy date or product-support end date. No Honeywell document reviewed for this page identifies a direct, one-for-one DWR06 successor.
Is another model a complete replacement?
No model should be described as a complete replacement without application-level verification. Similar pressure range alone is insufficient.
- 0.1–0.6 bar switching range and required reset point
- Fixed or adjustable switching differential
- Maximum permissible pressure and process medium
- G 1/2 A / G 1/4 pressure connection and sealing method
- SPDT contact logic, electrical load and wiring
- IP rating, ambient temperature and mounting position
- TÜV/DVGW or application-specific approvals
- Installed dimensions and safety-circuit validation
Related DWR06 configurations
These Honeywell configurations have different functions and are not automatically interchangeable with standard DWR06:
DWR06-203: adjustable switching differential.
DWR06-205: maximum-pressure limiter with mechanical interlock/reset.
DWR06-206: minimum-pressure limiter with mechanical interlock/reset.
DWR06-213: gold-plated contacts for defined low-voltage loads.
DWR06-205: maximum-pressure limiter with mechanical interlock/reset.
DWR06-206: minimum-pressure limiter with mechanical interlock/reset.
DWR06-213: gold-plated contacts for defined low-voltage loads.
A change to an electronic switch or another DWR configuration can require wiring, power supply, mechanical connection, programming, approvals and safety documentation changes. Treat it as an engineered migration, not a drop-in swap.
Buyer Support
Frequently Asked Questions
What is the pressure range of Honeywell FEMA DWR06?
DWR06 has an adjustable pressure range of 0.1 to 0.6 bar, a switching differential of 10 to 50 mbar and a maximum permissible pressure of 6 bar.
How does Honeywell FEMA DWR06 switch as pressure rises?
The scale is calibrated for rising pressure. At rising pressure, contact 3–1 opens and contact 3–2 closes. The reset point is lower than the switching point by the switching differential.
When was Honeywell FEMA DWR06 discontinued?
Honeywell marks the DWR Pressure Monitor series as discontinued, but the public product page does not provide a discontinuation date, last-time-buy date or support end date.
Which model directly replaces Honeywell FEMA DWR06?
Honeywell does not identify a direct one-for-one successor in the public official documents reviewed for this page. DWR06-203, -205, -206 and -213 are functionally different configurations, not automatic replacements.
What information is needed to evaluate a DWR06 replacement?
Provide the full nameplate, application medium, switching and reset pressures, electrical load, wiring, pressure connection, mounting arrangement, required approvals and clear installation photos. A qualified engineer should validate any safety-related change.
