Product Name	ProSoft RLX2-IHNF-W-A Weatherproof Industrial Frequency Hopping Radio
Item NO.	2897785
Weight	0.17 kg = 0.3748 lb = 5.9966 oz
Category	Prosoft
Brand	Prosoft
Creation Time	2026-08-19

ProSoft RLX2-IHNF-W-A | Weatherproof Industrial Frequency Hopping Radio

ProSoft RLX2-IHNF-W-A

Weatherproof Industrial Frequency Hopping Radio

Outdoor Rated 900 MHz

Key Information

The ProSoft RLX2-IHNF-W-A is a weatherproof industrial frequency hopping radio designed for outdoor wireless Ethernet communication in demanding environments. Operating in the 902-928 MHz ISM band, it provides license-free connectivity for SCADA systems, remote monitoring, and outdoor mobile equipment networking. The weatherproof enclosure allows direct installation in outdoor locations without additional protective housing, reducing installation complexity and cost.

Functions

• Transparent Ethernet bridging for any TCP/IP protocol.
• Frequency hopping spread spectrum for excellent interference immunity.
• Point-to-point, point-to-multipoint, and repeater modes.
• Weatherproof enclosure for direct outdoor mounting.
• Built-in serial server for RS-232/485 devices.

Specifications

Brand	ProSoft Technology
Model	RLX2-IHNF-W-A
Product Type	Weatherproof Industrial Frequency Hopping Radio
Frequency Band	902-928 MHz ISM
RF Data Rate	Up to 1.1 Mbps
Transmit Power	Up to 1 W (30 dBm)
Range	Up to 5 km with high-gain antenna
Ethernet Port	1 x 10/100 Mbps RJ45
Serial Port	1 x RS-232/485 (DB9)
Antenna Connector	N-type female
Enclosure Rating	Weatherproof (IP66)
Operating Temperature	-40°C to 75°C
Input Voltage	10-30 VDC
Certifications	FCC Part 15, IC, CE
Dimensions	200 x 150 x 80 mm
Weight	1.2 kg

Installation

The RLX2-IHNF-W-A is designed for direct outdoor installation with its weatherproof enclosure. It can be pole-mounted or wall-mounted using the included mounting brackets. The radio requires a suitable 900 MHz antenna connected via the N-type female connector. Power is supplied through a weatherproof cable gland. Configuration is performed using ProSoft Wireless Designer software via the Ethernet port. Proper grounding and lightning protection are recommended for outdoor installations.

Lifecycle Status

Lifecycle Status: Active / Mature. No immediate discontinuation notice. Replacement/Alternate: ProSoft RLX2-IHNF-W-E for enhanced features or RLX2-IHW for higher bandwidth requirements.

Related Models

• ProSoft RLX2-IHNF-A — Standard indoor frequency hopping radio.
• ProSoft RLX2-IHNF-E — Enhanced frequency hopping radio.
• ProSoft RLX2-IHNF-W-E — Weatherproof enhanced radio.
• ProSoft RLX2-IHW — High-speed industrial wireless radio.
