Modbus TCP/IP Services
The gateway provides Modbus TCP/IP client and server operation. Up to 160 client commands can be configured, and the internal database provides 10,000 16-bit registers for data transfer.
Product Overview
Protocol Conversion Across Separate Ethernet Networks
The ProSoft PLX32-MBTCP-PND connects a PROFINET controller with Modbus TCP/IP equipment. Its dual-port architecture keeps the two protocols on separate subnets while the gateway transfers mapped data between them.
The unit operates as a PROFINET Class A Device and supports both Modbus TCP/IP client and server functions. Configuration and diagnostics can be performed remotely through the Ethernet interfaces.
Product Specifications
PLX32-MBTCP-PND Technical Data
| Product type | Modbus TCP/IP to PROFINET Device gateway |
|---|---|
| PROFINET role | Class A Device (slave) |
| Ethernet interfaces | 2 × 10/100 Ethernet ports |
| Supported Modbus clients | 10 |
| Supported Modbus servers | 5 MBAP plus 5 Encapsulated |
| Configurable client commands | Up to 160 |
| PROFINET cyclic data | 1440 bytes input and 1440 bytes output |
| Internal database | 10,000 16-bit registers |
| Power supply | 24 VDC nominal; 10 to 36 VDC |
| Current draw | 300 mA nominal; 610 mA maximum |
| Operating temperature | -25 to 70 °C |
| Storage temperature | -40 to 80 °C |
| Relative humidity | 5 to 95%, non-condensing |
| Shock | 15 g operational; 30 g non-operational |
| Vibration | 5 g, 10 to 150 Hz |
| Dimensions (H × W × D) | 13.67 × 5.05 × 11.13 cm |
| Removable storage | Optional SD card |
Operating Functions
Deterministic Data Exchange
PROFINET Device Operation
As a PROFINET Class A Device, the PLX32-MBTCP-PND exchanges up to 1440 bytes of cyclic input data and 1440 bytes of cyclic output data with the controller.
Network Integration
Dual-Network Installation Architecture
Separated Ethernet Segments
Two Ethernet ports allow the Modbus TCP/IP and PROFINET networks to remain on separate subnets. This supports installations where control and device networks require distinct addressing.
Configuration and Diagnostics
Remote configuration and diagnostic access are available through the Ethernet interfaces. An optional SD card supports configuration storage and recovery workflows defined by ProSoft.
Frequently Asked Questions
PLX32-MBTCP-PND FAQ
What protocols does the PLX32-MBTCP-PND connect?
The PLX32-MBTCP-PND provides bi-directional data exchange between a PROFINET controller and Modbus TCP/IP client or server devices.
How many Ethernet ports does the PLX32-MBTCP-PND provide?
The PLX32-MBTCP-PND has two 10/100 Ethernet ports, supporting separate PROFINET and Modbus TCP/IP network segments.
How much PROFINET cyclic data can the PLX32-MBTCP-PND exchange?
The PLX32-MBTCP-PND supports 1440 bytes of input data and 1440 bytes of output data.
What Modbus TCP/IP connection capacity does the PLX32-MBTCP-PND support?
The PLX32-MBTCP-PND supports 10 clients and 10 server connections: five MBAP and five Encapsulated.
What DC supply range does the PLX32-MBTCP-PND require?
The PLX32-MBTCP-PND uses a 24 VDC nominal supply and accepts 10 to 36 VDC, with 300 mA nominal and 610 mA maximum current draw.
