Copy| Product Name | Motorola MVME162-520 VMEbus Embedded Controller |
| Item NO. | 2898067 |
| Weight | 0.17 kg = 0.3748 lb = 5.9966 oz |
| Category | MOTOROLA |
| Brand | MOTOROLA |
| Creation Time | 2026-08-20 |
Motorola VME Embedded Controller
A 32 MHz MVME162FX VMEbus embedded controller with 8MB shared DRAM and four IndustryPack interfaces.
Product Overview
A 32 MHz MVME162FX VMEbus embedded controller with 8MB shared DRAM and four IndustryPack interfaces.
The specification below follows the exact Motorola order designation and excludes family options that are not documented for this configuration.
Product Specifications
| Product family | MVME162FX |
|---|---|
| Processor | MC68040 with MMU and FPU |
| Processor clock | 32 MHz |
| DRAM | 8MB shared DRAM without parity |
| Local SRAM / NVRAM | 512KB battery-backed SRAM |
| Integrated I/O configuration | No SCSI or Ethernet |
| Serial interfaces | Two ports; console EIA-232-D DTE and configurable second interface |
| SCSI interface | Not fitted |
| Ethernet interface | Not fitted |
| Ordering note | Motorola tables identify the base model as MVME162-520 and later revision notation as MVME162-520A |
| Form factor | 6U VMEbus embedded controller |
| Flash memory | 1MB |
| Nonvolatile memory | 8K × 8 NVRAM and time-of-day clock with battery backup |
| Expansion | Four IndustryPack interfaces |
| Timers | Six 32-bit timers and watchdog timer when VMEbus is present |
| VMEbus addressing/data | A16/A24/A32 and D8/D16/D32; D64 block transfer on supported VMEbus models |
| Operating temperature | 0 to 70 °C exit air with forced-air cooling |
| Storage temperature | -40 to 85 °C |
| Relative humidity | 5 to 90%, non-condensing |
| Power, +5 V | 3.5 A typical; 4.5 A maximum |
| Power, +12 V | 100 mA maximum |
| Power, -12 V | 100 mA maximum |
| Board dimensions | 233 × 160 × 17 mm |
| With connectors/front panel | 262 × 188 × 20 mm |
Operating Functions
MVME162-520 combines the documented processor, local memory and on-board interfaces in one VMEbus controller. Its timers, nonvolatile resources and IndustryPack expansion operate within the board architecture defined by Motorola.
Serial interfaces: Two ports; console EIA-232-D DTE and configurable second interface. SCSI interface: Not fitted. Ethernet interface: Not fitted.
Installation Highlights
Install MVME162-520 only with power removed. Confirm slot, airflow, serial-interface module and transition-module settings against the Motorola installation manual before applying power.
Match the complete MVME162-520 designation before installation. Processor, memory, Ethernet, SCSI and VMEbus options vary by order code.
Frequently Asked Questions
MVME162-520 uses the documented MC68040 with MMU and FPU processor configuration at 32 MHz.
MVME162-520 provides 8MB shared DRAM without parity.
MVME162-520 is documented with No SCSI or Ethernet.
MVME162-520 is a MVME162FX embedded controller with the VMEbus and IndustryPack expansion resources stated in the official Motorola documentation.
MVME162-520 should be checked against the chassis power, airflow, jumper, serial-interface and transition-module requirements documented for this exact configuration.
