MTL 9469-ET Intrinsically Safe Wireless Access Point / Bridge Item NO.: 2820595

Manager: Leonia

Email: sales@mvme.cn | Whatsapp: +8618030175807

Moore Automation - Your Automation Spare Parts Trader

Looking for high-quality automation parts? Our team at Moore Automation is ready to assist you with reliable

and cost-effective solutions. Reach out today!

Manufacturer: MTL
Product Numbers: 9469-ET
Product Type: Intrinsically Safe Wireless Access Point / Bridge
Place of 0rigin: U.K.
Input voltage: 12V DC (9.5–12.8V)
Input current: 270mA
Input protection: Fuse + supply reversal diode
IS ETHERNET: Intrinsically Safe 10/100 base T
Connector: RJ45
PoEx: Powered Device
Frequency range: 2.4 / 5 / 5.4GHz
Data Rate: up to 108Mbps
Rapid Roaming: <50ms
Antenna connector: 2 x Female SMA - standard polarity
Operating: −40°C to +60°C
Storage: −40°C to +60°C
Relative Humidity: 5 to 95% RH (non-condensing)

The 9469-ET is a multi-functional module that can be used as an Access Point, Wireless Bridge (Client) or  Wireless Repeater When used

in the Access Point (AP) mode, it allows wireless devices to connect through it and onto the wired  Ethernet network, either in AD-HOC or

Infrastructure modes.When used as a Bridge, it makes it possible to turn any 10/100 Ethernet device into a wireless device, or to connect

two network segments together to make a single network (without the interconnecting wire or fibre optic).

Additionally the module may also be used in its Wireless Repeater (WDS) mode to extend the range covered by a wireless network. The

9469-ET is designed for hazardous-area mounting inside a suitable enclosure with intrinsically safe Zone 1, ATEX and IECEx certification and

Division 1 FM USA and Canada approvals.  The ATEX and IECEx approvals cover both surface industry and mining applications.

:
