Input group
IC200UEC008 / IC200UEC108: each unit provides four 24 Vdc inputs with positive/negative logic sensing. The channel assignment remains part of the commissioning record.
IC200UEC008VersaMax 8-point protected I/O expansion units
General Electric · VersaMax Micro expansion I/O
General Electric IC200UEC008 / IC200UEC108 | VersaMax 8-point protected I/O expansion units
IC200UEC008 / IC200UEC108 · VersaMax 8-point protected I/O expansion units
01
Product Details
VersaMax Micro expansion I/OGeneral Electric IC200UEC008 and IC200UEC108 are 8-point VersaMax expansion units with four 24 Vdc inputs and four protected transistor outputs. They add a compact input/output group to a VersaMax CPU through the expansion connector.
The two General Electric variants share the 4-input/4-output structure but use different output logic executions: UEC008 is a sourcing output unit with ESCP protection, while UEC108 is a sinking output unit. Their status LEDs and ribbon-cable expansion interface keep the added I/O visible in the controller record.
02
Specification Summary
Exact model configuration| Technical Item | IC200UEC008 | IC200UEC108 |
|---|---|---|
| Brand | General Electric | |
| Product name | VersaMax 8-point protected I/O expansion units | |
| Country | United States | |
| Points | 4 inputs + 4 transistor outputs | |
| Inputs | 24 Vdc, 4 channels | |
| Output current | 0.7 A per point; 3 A per common | |
| Output response | 0.05 ms maximum | |
| Input response | 4 ms typical | |
| Auxiliary supply | 24 Vdc, 200 mA | |
| Supply range | 24 Vdc nominal, -20%/+25% | |
| Isolation | 1500 V RMS field-to-logic; 500 V between groups | |
| Expansion cable | 0.1 m ribbon cable | |
| Maximum PLC distance | 2 m | |
| Status | Front I/O status LEDs | |
| outputs | Sourcing transistor outputs with ESCP | Sinking transistor outputs |
03
Product Functions
VersaMax 8-point protected I/O expansion unitsThe General Electric IC200UEC008 / IC200UEC108 pair adds protected 24 Vdc discrete I/O to a VersaMax Micro system. This detail belongs to the selected configuration and should not be inferred from the base family alone.
Output execution
IC200UEC008 / IC200UEC108: uEC008 provides sourcing transistor outputs with ESCP; UEC108 provides sinking transistor outputs. The receiving circuit must match this output execution.
Protection
IC200UEC008 / IC200UEC108: the transistor output circuits include short-circuit and overload protection behavior for the protected I/O arrangement. This detail belongs to the selected configuration and should not be inferred from the base family alone.
04
Installation Highlights
VersaMax Micro expansion I/OIC200UEC008 / IC200UEC108: the physical expansion path determines whether General Electric IC200UEC008 or IC200UEC108 fits the existing VersaMax panel. This detail belongs to the selected configuration and should not be inferred from the base family alone.
Expansion connector
IC200UEC008 / IC200UEC108: a left/right expansion connector and 0.1 m ribbon cable connect the unit to the controller or adjacent expansion unit. This detail belongs to the selected configuration and should not be inferred from the base family alone.
Distance
IC200UEC008 / IC200UEC108: the expansion cable path is limited to 2 m from the PLC. This detail belongs to the selected configuration and should not be inferred from the base family alone.
Status indication
IC200UEC008 / IC200UEC108: front status LEDs identify the operating and I/O state without changing the field terminal wiring. This detail belongs to the selected configuration and should not be inferred from the base family alone.
05
Frequently Asked Questions
Questions tied to the exact modelHow do General Electric IC200UEC008 and IC200UEC108 differ?
General Electric IC200UEC008 uses sourcing transistor outputs with ESCP, while General Electric IC200UEC108 uses sinking transistor outputs; both provide four inputs and four outputs.
What load limit applies to General Electric IC200UEC008?
The protected transistor outputs are rated 0.7 A per point and 3 A per common within the specified 24 Vdc supply arrangement.
Why does the output logic matter on General Electric IC200UEC108?
A sinking output switches the load toward the reference side, so the field device wiring must match the sinking circuit rather than the sourcing arrangement of UEC008.
How far can General Electric IC200UEC008 be placed from the PLC?
The expansion cable path is limited to 2 m from the PLC, using the 0.1 m ribbon-cable expansion interface.
What does ESCP provide on General Electric IC200UEC008?
ESCP is the protected output execution identified for UEC008; it is not a substitute for selecting the correct load wiring and external protection.
What indicates a field-side issue on General Electric IC200UEC108?
Use the front status LEDs and the input/output terminal measurements to separate a field wiring problem from an expansion-bus or logic problem.
