Product Name Horner HE800DQM306 / HE800DQM406 SmartStack Metal 10–30 VDC Sourcing Output Module
Item NO. 2906820
Weight 0.1 kg = 0.2205 lb = 3.5274 oz
Category GE
Brand GE
Creation Time 2026-09-09

Horner HE800DQM306 / HE800DQM406 SmartStack Metal 10–30 VDC Sourcing Output Modules
SmartStack Metal Outputs

Horner HE800DQM306 / HE800DQM406 SmartStack Metal 10–30 VDC Sourcing Output Modules

16 or 32 DC outputs0.5 A per outputShort-circuit protected

Product Overview

Horner HE800DQM306 and HE800DQM406 are SmartStack Metal positive-logic DC output modules. HE800DQM306 provides 16 outputs and one power common; HE800DQM406 provides 32 outputs and two power commons.

Both variants use current-sourcing outputs with a 10 kΩ pull-down, operate from 10–30 VDC and allow up to 0.5 A per output. The datasheet specifies short-circuit protection and a 650 mA maximum inrush current per channel.

Horner lists SmartStack Metal as a legacy product family. These metal-encased modules are used only with controllers or bases that support the metal SmartStack form.

16 / 32Output choices
10–30 VDCOperating range
0.5 AMaximum load per output
1 msON and OFF response

Product Specifications

Specification Details
Brand Horner
Model HE800DQM306 / HE800DQM406
Product Type SmartStack Metal 10–30 VDC Sourcing Output Modules
Country of Origin United States
Specification HE800DQM306 HE800DQM406
Outputs per module 16 32
Power commons 1 2
Operating voltage 10–30 VDC 10–30 VDC
Output type Sourcing, 10 kΩ pull-down Sourcing, 10 kΩ pull-down
Peak voltage 28 VDC maximum 28 VDC maximum
Maximum load current 0.5 A per output 0.5 A per output
Maximum inrush current 650 mA per channel 650 mA per channel
Minimum load None None
ON / OFF response 1 ms / 1 ms 1 ms / 1 ms
Output protection Short circuit Short circuit
Steady-state module power 0.12 W (5 mA at 24 VDC) 0.12 W (5 mA at 24 VDC)
Inrush power Negligible Negligible
Operating temperature 0–60 °C 0–60 °C
Relative humidity 5–95%, non-condensing 5–95%, non-condensing
Weight 9 oz (256 g) 9 oz (256 g)
Terminal type Spring clamp, removable Spring clamp, removable
Compliance CE; UL CE; UL

Output Performance and Protection

Fast sourcing outputs with ESCP

Each output is a current-sourcing channel rated at 0.5 A maximum, with 1 ms switching response and short-circuit protection. The 32-point HE800DQM406 separates its outputs across two power commons.

  • Maximum per-channel inrush is 650 mA.
  • No minimum load is specified.
  • Use the external load supply within the stated operating range.

Connection and Power Grouping

One or two load-power groups

The official connector drawing shows the first 16 outputs and their load-power terminals. The HE800DQM406 adds the second connector group for outputs 17–32.

  • HE800DQM306 uses one power common.
  • HE800DQM406 uses two power commons.
  • Match each load group to its designated load-power and common terminals.
Horner HE800DQM306 and HE800DQM406 output connector wiringClick to enlarge
Horner HE800DQM306 and HE800DQM406 output connector wiring

Frequently Asked Questions

How many outputs do HE800DQM306 and HE800DQM406 provide?

HE800DQM306 provides 16 outputs; HE800DQM406 provides 32.

Which output technology is used by HE800DQM306 and HE800DQM406?

Both use current-sourcing positive-logic outputs with a 10 kΩ pull-down.

How should load current be limited for HE800DQM306 and HE800DQM406?

Each output is limited to 0.5 A maximum, with 650 mA maximum inrush per channel.

Which protection is built into HE800DQM306 and HE800DQM406?

Both modules include short-circuit protection.

Are HE800DQM306 and HE800DQM406 current Horner products?

They belong to the SmartStack Metal legacy family and are not available for order.
