Horner HE800ADC110 / HE800ADC120 SmartStack Analog Input Modules
Four-channel voltage or current acquisition for a compatible SmartStack controller.
Product Description
HE800ADC110 and HE800ADC120 are four-channel, 12-bit SmartStack analog input modules for supported metal SmartStack controller assemblies. The voltage version accepts 0–5 Vdc, ±5 Vdc, 0–10 Vdc and ±10 Vdc ranges; the current version is intended for 0–20 mA and ±20 mA measurement ranges.
Both modules use removable spring-clamp terminals, have no external power-supply requirement, and update at the PLC scan rate. They are separate catalog choices: voltage signal conditioning and current-loop input impedance must match the installed field circuit before a replacement is selected.
Technical Specifications
| Specification | HE800ADC110 | HE800ADC120 |
|---|---|---|
| Brand | Horner | |
| Product Type | 4-channel 12-bit voltage input | 4-channel 12-bit current input |
| Country of Origin | United States | |
| System Family | SmartStack Metal | |
| Channels | 4 | |
| Signal range | 0–5 Vdc, ±5 Vdc, 0–10 Vdc, ±10 Vdc | 0–20.47 mA, ±20.47 mA nominal |
| Converter | Successive approximation | |
| Accuracy at 25°C | 0.05% full scale | |
| Operating temperature | 0–60°C | |
| Relative humidity | 5–95% non-condensing | |
| Terminal type | Spring clamp, removable | |
| Steady-state power | 0.09 W (4.1 mA at 24 Vdc) | |
| Weight | 9 oz. (256 g) | |
Signal Selection and Channel Use
HE800ADC110 provides four voltage input channels. Its nominal input impedance is 10 MΩ below 12 Vdc and 6 MΩ above 12 Vdc; digital filtering is available for the voltage input path.
HE800ADC120 provides four current input channels. Its input impedance is 100 Ω below 12 Vdc and the current input is clamped at 12 Vdc with 35 mA maximum continuous current.
Wiring and Configuration
Frequently Asked Questions
How should HE800ADC110 and HE800ADC120 be separated at selection time?
Select HE800ADC110 for the documented voltage ranges and HE800ADC120 for the documented current ranges. Do not exchange them only because both have four analog channels.
Which field-side detail matters before wiring HE800ADC110 and HE800ADC120?
Confirm whether the installed circuit is a voltage signal or a current loop, then identify each channel plus, common and shield connection.
How do HE800ADC110 and HE800ADC120 handle controller updates?
Both HE800ADC110 and HE800ADC120 use a conversion time set by the PLC scan rate; point assignment follows the installed SmartStack location.
What terminal style is used by HE800ADC110 and HE800ADC120?
Both HE800ADC110 and HE800ADC120 use removable spring-clamp terminals.
What should be recorded before replacing HE800ADC110 and HE800ADC120?
Record the full catalog number, the selected signal range, the installed stack position and the field conductor mapping for HE800ADC110 and HE800ADC120.
What environmental conditions apply to HE800ADC110 and HE800ADC120?
Both HE800ADC110 and HE800ADC120 are specified for 0–60°C and 5–95% non-condensing relative humidity.
