Emerson KJ1501X1-BC5 System DC Power Supply M-Series (DC/DC) Item NO.: 2821472

The Emerson KJ1501X1-BC5 AI 8-Channel 4-20mA HART Card Series 2 is a high-precision analog input module designed for

advanced industrial automation and process control applications. It supports 8 channels of 4-20mA HART signals, enabling

accurate and reliable data acquisition from field instruments. The module operates with 12 VDC at 13.8 A or 24 VDC at 4.5 A

input, providing output ratings of 5.1 VDC at 2.0 A and 3.4 VDC at 2.0 A, with total output power of 10.2 W. It also includes an

alarm contact rated at 30 VDC, 2.0 A to notify system events.
Designed for demanding environments, the module functions reliably across a wide ambient temperature range of –40°C to +70°C,

with shock resistance of 10 g half-sine wave for 11 ms and vibration tolerance of 1 mm peak-to-peak from 2 to 13.2 Hz; 0.7 g from

13.2 to 150 Hz. It meets ISA-S71.04 Class G3 airborne contaminant standards and supports 5–95% non-condensing relative

humidity, ensuring long-term performance and durability in industrial control systems.

Manufacturer: Emerson
Product Numbers: KJ1501X1-BC5
Product Type: AI 8 CH 4-20mA Hart Card Series 2
Place of 0rigin: USA
Condition: 100% Original
Warranty: 1 Year
Power Specifications
Input Rating: 12 VDC at 13.8 A
                      24 VDC at 4.5 A
Output Rating: 5.1 VDC at 2.0 A
                        3.4 VDC at 2.0 A
(40°C to +60°C): 12 VDC at 13 A (12 VDC input)
                            12 VDC at 8 A (24 VDC input)
(40°C to +70°C): 12 VDC at 10 A (12 VDC input)
                            12 VDC at 6 A (24 VDC input)
Output Power: 10.2 W (total from +5.1 VDC and +3.4 VDC)
Alarm Contact Rating: 30 VDC at 2.0 A
Environmental Specifications
Ambient Temperature: -40°C to +60°C...+70°C
Shock: 10g ½ Sinewave for 11msec
Vibration: 1mm Peak to Peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz
Airborne Contaminants: ISA-S71.04 –1985 Airborne Contaminants Class G3
Relative Humidity: 5 to 95% Non-Condensing
