ABB PM867K01 3BSE076355R1 AC 800M High Integrity Controller Kit
01
Product Description
ABB PM867K01 3BSE076355R1 is an AC 800M high-integrity controller kit that executes standard and SIL application code, coordinates S800 I/O and supports redundant controller operation through the platform communication structure. The kit combines the PM867 CPU with the TP830 processor base and defined bus accessories.
Inside ABB PM867K01 3BSE076355R1, the processor works with 64 MB SDRAM and firmware flash while CN1/CN2, COM3 and COM4 separate control-network, serial-protocol and service traffic. Electrical and optical ModuleBus paths extend process data to S800 I/O, and CEX units add only the documented communication interfaces.
High-integrity use of ABB PM867K01 3BSE076355R1 depends on the configured SM812 and certified software path, not on the CPU alone. Redundant projects preserve primary/backup roles, controller addresses and synchronized application state before a switchover test is accepted.
02
Product Specifications
Exact-model engineering data
| Brand | ABB |
|---|---|
| Model | PM867K01 3BSE076355R1 |
| Product Name | AC 800M High Integrity Controller Kit |
| Country | Switzerland |
| System Family | AC 800M |
| Processor | MPC866, 133 MHz |
| Memory | 64 MB SDRAM; 4 MB firmware flash |
| Power Supply | 24 V DC nominal; 19.2 to 30 V DC |
| Current Consumption | 210 mA typical; 360 mA maximum |
| Power Dissipation | 5.1 W typical; 8.6 W with full bus supply |
| Power Reservoir | 5 ms |
| Communication | CN1/CN2 Ethernet; COM3/COM4 serial |
| ModuleBus | Electrical and optical S800 I/O connection |
| Dimensions | 119 × 186 × 135 mm |
| Package Weight | Approx. 1.2 kg |
03
Configuration and Programming
ABB PM867K01 3BSE076355R1 is configured as a controller, communication endpoint and—where required—high-integrity execution node within one controlled project.
Network and bus mapping
CN1/CN2 addresses, serial settings, CEX positions and ModuleBus I/O identities are mapped to their physical connections before download.
High-integrity project
SIL application code is compiled and loaded through the certified engineering path with the specified SM812 arrangement; ordinary code remains separated by the project structure.
04
Diagnostics and Protection
Diagnostics for ABB PM867K01 3BSE076355R1 combine CPU state, power supervision, communication LEDs and redundancy status so one indication is not used as a substitute for a complete fault check.
Power supervision
L+/L− supply and SA/SB status inputs are checked with the ModuleBus/CEX load, because a healthy feeder does not prove every downstream bus is powered.
Controller-state checks
RUN, STOP, ERROR and battery indications are read together with the engineering diagnostics and event record.
Redundancy verification
Primary and backup identities, synchronization and communication paths are confirmed before and after a controlled switchover.
05
Common Questions
What must be configured before downloading ABB PM867K01 3BSE076355R1?
Before downloading ABB PM867K01 3BSE076355R1, match the CPU article, firmware, control-network addresses, CEX layout, ModuleBus I/O and high-integrity project settings.
How is controller redundancy verified on ABB PM867K01 3BSE076355R1?
For ABB PM867K01 3BSE076355R1, confirm primary and backup roles, synchronized application state and both communication paths, then perform the documented controlled switchover test.
Can ABB PM867K01 3BSE076355R1 run safety code without the full safety arrangement?
No. ABB PM867K01 3BSE076355R1 requires the documented SM812 and certified software/project path for high-integrity execution.
Why does ABB PM867K01 3BSE076355R1 show power but no I/O data?
On ABB PM867K01 3BSE076355R1, check ModuleBus power, terminators, optical/electrical connections and the configured I/O identities instead of treating the CPU power LED as proof of the I/O path.
What is preserved before replacing ABB PM867K01 3BSE076355R1?
Preserve the project, retain data, firmware, IP addresses, redundancy role and CEX/ModuleBus layout for ABB PM867K01 3BSE076355R1 before removal.
Which ports have different roles on ABB PM867K01 3BSE076355R1?
ABB PM867K01 3BSE076355R1 uses CN1/CN2 for Ethernet control-network paths, COM3 for serial protocol and COM4 for the documented service connection.
